Pontiac Pump Gas Street Engine Combinations
When building a killer Pontiac pump gas street engine,
we feel that the combination of parts tends to be even more critical. The parts need to match
and compliment each other in order to optimize performance.
When building a Pontiac engine, the selection of cylinder heads, camshaft, and intake are critical to
building the right combination and making maximum power from off idle to redline.
Having access to a Superflow 901 dynamometer for engine break in
and tuning helps us get the most out of your combination in a very cost
effective and thorough manner.
|
475 Horsepower 553 ft lbs of Torque

461 cid Pontiac engine can be
built with a stock Pontiac block or an MR-1 aftermarket block.
Engine uses a Crower hydraulic flat tappet cam, PRO Sport Cast
Crankshaft, PRO Sport 6.625 rods, Federal Mogul rod and main bearings,
Durabond cam bearings, Melling Oil pump, Edelbrock Performer RPM intake,
850 Qjet carburetor, 1 3/4 header, Rhodes lifters, 85 cc KRE Aluminum D
port heads (stock NO PORT WORK!) with total timing set at 31 deg!
Engine runs on pump gas. TIP Complete Gasket Set, TIP Viton rear
main seal, Romac balancer, SRP piston
Dyno Sheet
Can run high 11's very low 12's
in a 3700 lb car with correct gearing and converter!
|
|
500
Horse 580 ft lbs of TORQUE Pump Gas Street Engine
|
|
520
Horse 585 ft lbs of TORQUE Pump Gas Street Engine
461 cid Pontiac engine can be
built with a stock Pontiac block or an MR-1 aftermarket block.
Engine uses a Comp Cam Custom ground Hydraulic roller camshaft, Comp Cams
Hydraulic roller lifters, PRO Sport Cast
Crankshaft, PRO Sport 6.625 rods, Federal Mogul rod and main bearings,
Durabond cam bearings, Melling Oil pump, Edelbrock Performer RPM intake,
850 Holley carburetor, 1 3/4 header, Crower Hydraulic lifters, 85 cc KRE Aluminum D
port heads gasket matched, 1.6 Scorpion rockers, TIP Complete Gasket Set, TIP Viton rear
main seal, Professional Producst balancer, Ross piston, Total Seal Rings
11.50s in a 3700 lb with correct converter and gear
|
|
550
Horse 580 ft lbs of TORQUE Pump Gas Street Engine

This
468 makes 550 hp @ 5300 rpm and 580 ft lbs of torque with the following
components: 74cc KRE 310
cfm Aluminum D port heads, Eagle Rods, Total Seal Rings, Ross Pistons,
TIP Gaskets, Professional
Product SFI damper, Crower hyd flat tappet cam, 1.75" Hedman
Headers, Scorpion Rockers, Torker II intake, and 850 Demon on pump gas.
Pro Street idle
Dyno
Sheet
Low 11's in a 3500 lb car
|
|
|
552
HP / 584 ft lbs of torque HR Pump Gas Engine
This
468 makes 552 hp @ 5400 rpm and 584 ft lbs of torque @ 4400 rpm with the following
components: 74cc KRE 310
cfm Aluminum D port heads, Eagle Rods, Total Seal Rings, SRP Pistons,
Eagle Cast crankshaft, TIP Gaskets, Professional
Product SFI damper, TIP Custom ground Comp Cams Hydraulic Roller
camshaft with Comp Cams hydraulic roller lifters, Scorpion Rockers,
1 /3/4 Doug's Headers, Hurricane intake, and 950 Holley HP carb n pump gas.
Idels at 800 rpm with noticeable lope.
Dyno
Sheet
|
|
600
HP Pump Gas Engine
This
462 makes 600 hp @ 5800 rpm and 596 ft lbs of torque @ 4700 rpm.
Engine pulls 13.9 inches of vacuum at 950 rpm. We used the following
components: 72cc 325 cfm
Edelbrock Aluminum heads, Eagle Rods, Total Seal Rings, Ross dished Pistons,
Pro Sport Forged, TIP Gaskets, Professional
Product SFI damper, TIP Custom ground Comp Cams Solid Roller
camshaft with Comp Cams hydraulic roller lifters, Harland Sharp,
2" Headers, Victor intake, and Holley HP1000 carb on pump gas.
Dyno
Sheet
high
10s in a 3500 lb car
|
|
650
HP Pump Gas Engine
More
info coming soon....
Dyno
Sheet
mid
10s in a 3500 lb car
|
|
680
HP Pump Gas Engine

Dyno
Sheet
This
505 makes 685 hp @ 6100 rpm and 658 ft lbs of torque with the following
components: MR-1 block, 85cc
340 cfm KRE D port heads, Scorpion rockers, TIP Custom Ground Comp solid roller cam and
valve train, Meziere electric water pump, Ross Pistons, Total Seal
rings, Romac Balancer, Moroso pan, Victor intake, 1050 Dominator, TIP gaskets, TIP
Viton Seal, Crower billet crank, Crower rods, TIP Crank mandrel system,
Moroso 4 vane vac pump, TIP logo valve covers, KRE stud girdle, Taylor
wires, MSD Distributor
Starting at $13,900
|
We
can rebuild your Pontiac engine with just about any modifications that you
desire. From mild to wild, from pure stock to high performance, we can do it!
We specialize in high horse power Pontiac engines.
| |
